YAMAHA 100HP
Χαρακτηριστικά
|
Engine type |
16-Valve, SOHC, In-line 4 cylinders |
|||
|
Displacement |
1832 cm³ |
|||
|
Bore x stroke |
81.0 × 88.9 mm |
|||
|
Compression ratio |
10.0 : 1 |
|||
|
Fuel induction system |
Fuel injection |
|||
|
Lubrication system |
Wet sump |
|||
|
Engine oil capacity |
3.2 L / 3.0 L (with / without oil filter replacement) |
|||
|
Ignition / advance system |
TCI |
|||
|
Alternator |
35 A (battery charging: 21 A) |
|||
|
Overall length |
803 mm |
|||
|
Overall width |
488 mm |
|||
|
Overall height |
L: 1622 mm, X: 1749 mm |
|||
|
Engine transom height |
L: 516 mm, X: 643 mm |
|||
|
Steering angle |
35 degrees each direction |
|||
|
Dry weight |
162 kg – 166 kg |
|||
|
Maximum propeller shaft output |
73.6 kW |
|||
|
Full throttle operating range |
5000 – 6000 r/min |
|||
|
Idling speed |
700 – 800 r/min |
|||
|
Shallow water drive |
PTT: variable position |
|||
|
Gear shift |
F-N-R |
|||
|
Gear ratio |
2.15 (28/13) |
|||
|
Gear oil capacity |
0.760 L |
